| Parameter | Specification |
|---|---|
| Frequency Range | DC - 6GHz |
| Impedance | 50 Ohm |
| Max Power Rating | 200 Watts |
| VSWR | ≤ 1.2:1 (DC-3GHz) |
| Insertion Loss | ≤ 0.25dB |
| Connector Type | N female to N Female |
| Mounting Type | 4-Hole Square Flange / Panel Mount |
| Surge Current Capacity | 20KA |
| Rated DC voltage | 230V |
| Body Material | Tri-metal / Nickel Plated Brass |
| Contact Material | Gold Plated Beryllium Copper |
| Operating Temperature | -45°C to +85°C |
