| Parameter | Specification |
|---|---|
| Frequency Range | DC - 3 GHz |
| Impedance | 50 Ohm |
| Max Power Rating | 200 Watts CW |
| VSWR | ≤ 1.2:1 (DC-3GHz) |
| Insertion Loss | ≤ 0.25dB |
| Connector Type | TNC male to TNC Female |
| Protection Type | Gas Discharge Tube (GDT) |
| DC Spark-over Voltage | 230V |
| Body Material | Tri-metal / Nickel Plated Brass |
| Contact Material | Gold Plated Beryllium Copper |
| Operating Temperature | -45°C to +85°C |
| IP Rating | IP67 (When installed in bulkhead) |
