Ensure uncompromising signal precision in extreme environments with our Non-Magnetic Cryogenic 2.92mm Attenuator. Engineered specifically for quantum computing, superconducting circuits, and dilution refrigerator applications, this premium RF attenuator operates flawlessly at ultra-low temperatures while maintaining strict non-magnetic properties to prevent field interference.
Delivering reliable performance up to 40 GHz, it handles up to 2 Watts of continuous power. The precision-machined 2.92mm (K-type) connectors ensure excellent VSWR, stable impedance matching, and secure mating. Designed to minimize thermal noise and provide accurate signal reduction, this attenuator is an essential component for highly sensitive, low-temperature microwave test setups and cryogenic research.
Key Features:
Technical Specifications：
|
2W Non-magnetic Cryogenic 2.92mm Attenuator DC-40GHz Technical Specifications:
|
|||
|
Nominal Impedance |
50ohm |
Frequency Range |
DC-40GHz |
|
VSWR |
≤1.25 |
Power Rating |
2W |
|
Temperature Range |
-260℃ to +125℃ |
||
|
Dimensions |
Φ9x17.2mm |
||
|
Attenuation & Accuracy |
1,2,3,4,5,6,7,8,9,10,20,30dB available, and 1-10dB(-0.7/+0.8),20.30dB(-0.8/+1) |
||
