| Parameter | Specification |
| Frequency Range | DC to 26.5 GHz |
| Connector A | SMA Male (Quick-Disconnect Push-Pull) |
| Connector B | SMA Female (Standard Threaded) |
| Impedance | 50 Ohms |
| VSWR (Max) | 1.2:1 (DC to 18 GHz) |
| 1.35:1 (18 to 26.5 GHz) | |
| Insertion Loss | 0.2dB |
| Body Material | Passivated Stainless Steel |
| Plating | Gold Plated (Center Contact & Outer Shell) |
| Temperature Range | -55°C to +125°C |
| Durability | > 2000 Mating Cycles |
