| Feature | Specification |
|---|---|
| Frequency Range | DC - 3.0 GHz |
| Interface A (Input) | BNC Male (Plug) |
| Interface B (Output) | TNC Female (Jack) |
| Power Handling | 200W CW |
| VSWR | ≤ 1.20:1 (DC-2GHz), ≤ 1.35:1 (3GHz) |
| Insertion Loss | ≤ 0.25 dB |
| Surge Current | 10kA (8/20µs) |
| Gas Tube Voltage | 90V or 230V (Replaceable) |
| DC Pass | Yes (Supports Active Antennas) |
| Body Material | Tri-metal or Nickel Plated Brass |
| Contact Material | Gold-plated Beryllium Copper |
